Advanced Plus Group Ltd

Bluetooth Match Name

G01

Battery Type

Polymer Battery

BT Version

5.4

Battery Capacity

120mAh

BT Chip

AB5656D

Charge Voltage/Current

5V 1A

Weight

28g

Size

64*49*21.80mm

Power Amplifier Types

Stereo Bone Conduction

Speaker

Bone Conduction Speaker

BT Range

10~15m

Support Profile

A2DP，AVRCP，HFP，HSP

   Accessories

User Manual、Type-C Charger Cable

Work Voltage

3.2~4.2V

Power Off Current

29uA

Power On Current

22mA~25mA

Play Current

30mA~70mA

Talking Current

30mA~70mA

Charge Current

130mA

Charge Voltage

DC:5V

Charge Complete DC Side Current

＜1mA

Output Power

N/A

Impedance

8ohm

SPK 1OOOHZ Sensitivity

72±3dB

Audio Frequency Range

100 Hz→10 kHz

MIC 1OOOHZ Sensitivity

-42±3db

Frequency Response Range

300HZ→3KHZ

Low Power Off Voltage

＜3.3V

Low Battery Alarm

＜3.3V

Battery Capacity

3.7V/120mAh

Music Time/Call Time

6-10H

Standby Time

240H

Charge Time

2H

Certificates

1:FCC ID

2: CE-RED

3: RoHS2.0

4: CE-EMC

5：Bone Conduction Patent

Battery Certificate:

1:IEC 62133-2

2:Hazardous Substance Testing For EU Battery Directive

3: UN 38.3，MSDS，DGM

Packing Details

1.Single Box Weight：67.8g，Color Box Dimension:103*50*137MM

2.40pcs/ctn，N.W:2.712KG，G.W:3.212KG，Carton Dimension: 52.5*29*22CM
